SECTION B
Factors From Differential Elements to Finite Areas

B-18: Planar element to elliptical plate in plane parallel to element. Normal to element passes through center of plate.

Reference: Siegel and Howell, 1992; Wong, 1977.

Definitions: A=a/h; B=b/h

Governing equation:

To download a copy of this equation in MS Word 97 Format, click HERE.
