SECTION C
Factors From Finite Areas to Finite Areas

C-123: Sphere to scalene triangle in plane perpendicular to sphere axis with one vertex on axis; sphere does not intersect plane of triangle.

Reference: Feingold and Gupta

Definitions:

B₁ = b₁/a

B₂ = b₂/b₁

B₃ = b₃/b₁

Governing Equation:

To download a copy of this equation in MS Word 97 Format, click HERE.
