SECTION C
Factors From Finite Areas to Finite Areas

C-15: Rectangle to rectangle in a perpendicular plane; all boundaries are parallel or perpendicular to x and x boundaries.(Form revised from Ehlert and Smith)(Note that the expression fails if the rectangles share a common edge)

Reference: Ehlert and Smith; see also Gross, Spindler and Hahne; Boeke and Wall; Chekhovskii, et al

Governing equation:

To download a copy of this equation in MS Word 97 Format, click HERE.
